Mobotix Mx-V16B-6D041 V16B Complete Cam 6MP, 1x B041 (Day)

V16B Vandalism with one 6MP Moonlight sensor day (3072 x 2048), HD premium lens B041 (f/1.8, horiz. image angle 90°) • ONVIF-compliant Mx6 system platform (2nd generation) with H.264, MxPEG+ and M-JPEG • 3-5 mm stainless steel casing • IK10++/IP65 • Functional range like S16 • HD Audio: Microphone and speaker integrated in the housing

Intro Web:
V16B Armored high-security dual lens camera day with 1 lens B041 (90° x 67°)

Camera Type:
Box Camera

Dual Camera:
Yes

Manual Lens Alignment:
No

Microphone:
Yes

Speaker:
Yes

Application Area:
Indoor
Outdoor

MxBus:
Yes

Housing Shape:
Vandal

Housing Color:
grey

Housing Material:
Stainless steel

Tamper Detection:
--

Camera and data security:
- User/Group management
- SSL
- IP address filter
- IEEE802.1x. Intrusion Detection
- digital image signature
- MxFFS

Camera Software (From Version):
5.1.0.x

Software Features:
- Multistreaming
- Multicast
- vPTZ
- Programmable exposure windows
- Single-frame capture
- Full featured recording (MxFFS Archive, continuous recording, full image recording with audio)
- Time and event controlled recording
- Weekly scheduled arming considering holy days
- Web functionality
- Logo generator
- Linked event logic
- Master/slave arming
- Several time-controlled pirivacy zones
- Custom voice messages
- VoIP phone
- Remote control
- Program interface/HTTP-API

Instructions:
--

Interfaces:
- Ethernet 100BaseT (MxRJ45 and LSA+)
- MiniUSB (MxMiniUSB)
- MxBus

Signal Input:
via Accessory (MX-232-IO-Box)

Signal Output:
via Accessory (MX-232-IO-Box)

RJ45 Ethernet Connectors:
1 (inside housing)

Weight Packaging (g):
4680

Height Packaging (mm):
260

Width Packaging (mm):
260

Length Packaging (mm):
260

Volume Packaging (l):
17.576

Material Packaging:
cardboard box, styrofoam

Height Product:
196

Width Product (mm):
260

Depth Product (mm):
180

Weight Product (g):
4680

Status LED:
2 (inside housing)

Controls:
1 (inside housing)

Power Consumption (W):
Typ. 7.5 W
Power consumption increases due to connected consumers:
- MxBUS max. 3 W
- USB max. 2.5 W
- total max. 4 W
Min: 5
Max: 7

Power Supply:
- PoE IEEE 802.3af
- PoE-Class 2/3 adjustable
- Factory Setting Class 3

Intended Use:
No EX Area, Corner mounting

Ambient Temperature (°C):
-40...+60 °C (-40 ... 140 °F; Operational temperature)
Cold start at -30 °C (-22 °F)

IP Class:
IP66

IK Class:
IK10++

Certificates:
- EN55032:2012
- EN55022:2010;
- EN55024:2010;
- EN50121-4:2015
- EN61000-6-1:2007;
- EN 61000-6-2:2005
- EN61000-6-3:2007+A1:2011
- EN61000-6-4:2007+A1:2011
- AS/ NZS CISPR22:2009+A1:2010
- CFR47 FCC part15B

MTBF (h):
80,000

PIR:
No

Audio:
- Microphone, 16bit/16kHz (HD-Wideband-Audio)
- Loudspeaker

DVR:
- Camera-internal via microSD card
- External on USB device
- External on NAS
- Full image recording regardless of live image zoom
- MxFFS
- Pre-alarm and post-alarm images
- DVR monitoring with error notification

Video Phone:
VoIP, SIP, two-way speaker, remote controlling of the camera in- and outputs, event notification

Intelligent Video Analysis:
- MxActivitySensor, video motion analysis
- Alarming via email, FTP, VoIP, speaker

Protocols:
IPv4, IPv6, HTTP, HTTPS, FTP, FTPS, RTP, RTSP, UDP, SNMP, SMTP, DHCP (Client or Server), NTP (Client and Server), SIP (Client and Server) G.711 (PCMA and PCMU) and G.722

Ethernet:
Ethernet 10/100, IPv4/IPv6, MiniUSB, MxBus, IO and RS232 via Interface Boxes (accessories)

Overvoltage Protection:
via MX-Overvoltage-Protection-Box

Mounting Options:
Corner

CPU:
i.MX 6 Dual Core incl. GPU

RAM:
1GB

Flash:
512 MB

FPGA:
Artix7

Image Angle horizontal:
90°

Image Angle vertical:
67°

Focal Length:
4.1 mm

Aperture:
f/1.8

Max. Frame Rate:
- MxPEG*: 42@HD(1280x720), 34@Full-HD, 24@QXGA, 15@5Mp, 12@6MP, 6@2x 6MP
- MJPEG*: 26@HD(1280x720), 13@Full-HD, 9@QXGA, 5@5Mp, 4@6MP, 2@2x 6MP
- H.264: 25@Full-HD, 20@QXGA

* Only Single Core used
Max: 42

Max. Image Size:
2x 6MP (3072x2048)

Lens(es):
- B041
- B079

Image Format:
Freely configurable format 4:3, 8:3, 16:9 or customized format (Image Cropping), like 2592x1944 (5MP), 2048x1536 (QXGA), 1920x1080 (Full-HD), 1280x960 (MEGA)

PTZ:
Digital pan/tilt/zoom; max. zoom 8x (continious)

Camera Optics:
Night
Day

Light Sensitivity:
- Color sensor (day): 0,1 lx @ 1/60s; 0,005 lx @ 1s
- BW sensor (night): 0,02 lx @ 1/60s; 0,001 lx @ 1s

Video Codecs:
- MxPEG+, M-JPEG, JPEG (max. output fromat 6MP)
- H.264 (max. output format QXGA; bandwith limitation possible)

Image Processing:
MxLEO, backlight compensation, automatic white balance, image distortion correction

ONVIF compatibility:
compatible

Image Sensor:
2x 1/1,8“ CMOS sensor, 6MP (3072x2048), progressive scan
