Planet PoE-162S High PoE+ Gigabit Ethernet Splitter (12V/24V)

Sale price$44.00
SKU: PoE-162S

Usually Ships in 10 - 12 days

Quantity:

Contact

Planet PoE-162S Features

Hardware Specifications

  • Ethernet Ports: “PoE (Power + Data)” Input Port: 1 x RJ-45 STP; “Data” Output Port: 1 x RJ-45 STP; DC Out Plug Connector: 1
  • Power Input: 802.3at PoE+ 52 ~ 56V DC
  • Data Rate: 10/100/1000Mbps (vary on Ethernet device attached)
  • Dip Switch: 12V DC / 24V DC output voltage
  • LED Display: System: Power x 1 (Green); PoE Port: PoE in Use x 1 (Green)

Power over Ethernet Specifications

  • PoE Standard: IEEE 802.3at High Power over Ethernet
  • PoE Power Supply Type: Mid-Span
  • PoE Power Output: 12V DC, 2A max. 24V DC, 1A max.
  • Standards Compliance: IEEE 802.3 10Base-T Ethernet; IEEE 802.3u 100Base-TX Fast Ethernet; IEEE 802.3ab 1000Base-T Gigabit Ethernet; IEEE 802.3at High Power over Ethernet

Planet PoE-162S Overview

PLANET has released next generation of Power over Ethernet Splitter product – POE-162S, compliant with brand-new IEEE 802.3at High Power over Ethernet standard that support 25.5 Watts for maximum input power. The POE-162S provides the following key features:

  ■ IEEE 802.3at Power over Ethernet Standard Compliant
  ■ 12V / 24V DC Power Output Through DIP Switch
  ■ Passive 10/100/1000Mbps Duplex Mode Support
  ■ Quick and Easy High Power PoE Network Deployment

The POE-162S is an IEEE 802.3at High Power over Ethernet Splitter that can split the 52 ~ 56V DC over the Ethernet cable into selectable 12V or 24V DC power output. It is designed specifically to fill the growing demand of higher power required network equipments such as PTZ (Pan, Tilt & Zoom) network cameras, PTZ Speed Dome camera, color touch- screen / Video and Voice over IP (VoIP) telephones, multi- channel (11a / b / g / n) wireless LAN access points and other network devices that need to work normally by higher power feeding than power via current IEEE 802.3af PoE standard. The POE-162S High Power Splitter is an ideal solution to transfer power to the network device with high power demand directly via the RJ-45 Port interface without the need to install power outlets and electrical cabling. With compact, slim type IP30 industrial case protection, the space saving Industrial High Power PoE Splitter IPOE-162S can be placed in almost any difficult environment. It allows either DIN rail or wall mounting for efficient use of cabinet space. Being able to operate under the temperature range from -40 to 75 degrees Celcius, the IPOE-162S is the ideal product for co-working with Industrial High Power Injector which can feed the power to Non-PoE devices up to 100 meters (328 feet) away on those harsh environments.

Quick and Easy High Power PoE Network Deployment
The POE-162S (Splitter) can work with the IEEE 802.3at Gigabit Power over Ethernet devices like POE-161, High Power PoE Switch and Media Converter (Injector, insert DC Voltage into Cat.5/5e/6 cable) to transfer data and power simultaneously into the end device. The POE-161, High Power Switch and Media Converter can combine the Ethernet digital data with power over the twisted pair cables as an IEEE 802.3at Gigabit Power over Ethernet Injector; and the POE-162S shall separate the digital data and the power into 12V / 24V DC power outputs. The maximum distance between the high power PoE injector and the splitter (POE-162S) is 100 meters. Unlike current Power over Ethernet Splitter, the POE-162S also supports passive 10/100/1000Mbps Ethernet connection ability.With IEEE 802.3at Gigabit High Power over Ethernet devices installed, the system administrator only has to use one single RJ-45 Ethernet cable to carry both power and data to each device. Besides, to connect through the high power PoE injector and the POE-162S, you could also have benefits including cost saving, easier for networking planning and higher reliability. Upon IEEE 802.3at compliant devices are installed, the high power PoE injector working together with the POE-162S can make the connection while migrating or splitting the power and the Ethernet digital packets.

The IEEE 802.3at Injector and Splitter Installation
Due to the capability of IEEE 802.3at standard, the POE-162S can co-work with the IEEE 802.3at Gigabit PoE injector devices like POE-161, High Power Switch or High Power Media Converter and transform non-PoE equipment to IEEE 802.3at PoE application. For a place which is hard to find the power inlet, the High Power PoE devices and the POE-162S operate as a pair, it provides the most easiest way to power your Ethernet devices that need high power input, such as PTZ (Pan, Tilt & Zoom) network cameras, PTZ Speed Dome Camera, color touch- screen Voice over IP (VoIP) telephones, and multi-channel wireless LAN access points.
